prs-csi-call-station-interface-2421

PRS-CRF Call stacker

  • Records calls for automatic playback to previously occupied zones (call stacker)
  • Acoustic feedback suppression by recording a call with delayed broadcast (time shifter)
  • Possibility to monitor a call before broadcasting
  • Records and/or plays back up to eight calls simultaneously
  • Stores up to 16 calls
  • Connects directly to Praesideo network
  • Hotline/Zalo/Viber hỗ trợ : 096 971 6035 - 098 330 1700 - 028 3838 1269
    • Danh mục: Từ khóa:

    PRS-CRF Call stacker

    PRS-CRF Call stacker

    Power consumption 4.2 W
    Frequency response 20 Hz to 20 kHz (-3 dB)
    S/N > 85 dB
    Crosstalk <-85 dB
    Dimensions (H x W x H)
        Without bracket 27 x 243 x 80 mm (1.1 x 9.6 x 3.1 in)
        With bracket 34 x 243 x 84 mm (1.3 x 9.6 x 3.3 in)
    Weight 0.7 kg (1.5 lb)
    Mounting Bracket (two screws)
    Color Charcoal
    Operating temperature -5 ºC to +55 ºC (+23 ºF to +131 ºF)
    Storage and transport temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF)
    Relative humidity 15 % to 90 %
    Air pressure 600 to 1100 hPa

    PRS-CRF Call stacker
