Am Li A – 1812

Rated Input 6 W Rated Impedance 1.7 kΩ (6 W), 3.3 kΩ (3 W), (6.7 kΩ (1.5 W), 13 kΩ (0.8 W): Internal wiring must be changed) Sound Pressure Level 90 dB (1 W, 1 m) Frequency Response 100 - 16,000 Hz Speaker Component 12 cm dynamic cone-type speaker Dimensions for Fixing Hole φ150 (mounting hole) × 50 (ceiling thickness) mm Speaker Mounting Method Spring catch Applicable Cables 600 V Vinyl-insulated cable (IV wire or HIV wire) Solid copper wire: φ0.8 - φ1.2 mm 7-core twisted copper wire: 0.75 - 1.25 m㎡ Connection Push-in connector (Bridging and branch connections possible.) Finish Grille: Fire-resistant, high-impact styrene resin (resin material grade: UL94 V-O or its equivalent), black Dimensions 215 (W) × 134 (H) × 89 (D) mm Weight 630 g Applicable Panel CP-70 series panel (option): CP-73, CP-77
